Available To Order

Quickly Troubleshoot Lighting, Air Brake and ABS Systems with the Industry’s Leading Mobile Universal Trailer Tester

This intuitive and durable design is ideal for both on and off-site commercial trailer testing and repairs.

ELECTRICAL TESTING(12/24 Volt Operation)

  • Power lights: Manually, all-on, auto scan, or by remote control
  • Audible and visual alerts: cross, open, overloaded and short circuit indication
  • Pulsar® mode allows diagnostic repair
  • Advanced trailer wiring diagnostics
  • Amperage readout and range (0-20 amps)
  • Cable testing
  • Ground failure detection: differentiates between wire and chassis ground

ABS TESTING

  • Access ABS blink codes
  • Test ABS fault blink codes via Auxiliary and Brake Circuit activation (i.e. Meritor/Wabco, Bendix® TABS-6 and Haldex systems)

AIR BRAKE TESTING

  • Performs leak-down test on service and emergency lines
  • Remote control allows observation of slackers to measure and adjust pushrods
  • Real-time, repetitive brake activation to find developing problems and verify leaking servo cans

REMOTE CONTROL

  • 12-button remote control tests all trailer electric circuitry and air brake actuation, 200 ft. range
  • Sync multiple (12) remotes to one unit

Read Our Full Trailer Testing Blog Here

#
SKU: 9008-4R

Face Shield

$82.95

#
SKU: 7900AP-2640AS

Air-In Fitting

$5.95

#
SKU: MUT-PRES-AS2

Pressure Gauge

$16.95

#
SKU: MUT-REG-AS

Regulator

$27.95

#
SKU: MUT-SOLX-AS

Solenoid

$16.95

Connection Type: 7-Way Round Pin
Power Input: 12/24V DC
Suggested Battery: Group 31 (or similar battery) or external 12 volt power source
Source Output: 20A @ 12V DC
Max Operating Pressure: 120 psi
Air Input: ¼” npt (120 psi max.)
Controls: Manual, Remote, Automatic
Tires: 10″ Pneumatic
Material: Powder-Coated Steel
Weight: 56 lbs.
Dimensions: 21″ L x 15″ W x 35″ H
Warranty: 3-Year Limited Warranty
CoO: USA
